Front Wheel Removal

Front Wheel Removal

Front Wheel Removal Step 1

Step 1

The first thing you will want to do is unhook the brake cable from the brake on the side that has the hook. It is circled in the attach image.

Front Wheel Removal Step 2

Step 2

Once you unhook the cable it should look like this image, showing enough space to remove the wheel without rubbing on the brake pads.

Front Wheel Removal Step 3

Step 3

Next you will want to remove the cap on the inner tube valve and press down (with maybe a pen if handy) on the inside of the valve to release the air. This will allow the tire to fit and slide out towards the final steps.

Front Wheel Removal Step 4

Step 4

The next step would be to remove the 2 screws that hold the cover.

Note: For Triton Pro, Triton, and Mobito models, you can skip over to step 6

Front Wheel Removal Step 5

Step 5

This image shows the cover pulled back.

Front Wheel Removal Step 6

Step 6

So now that one side of the brake is removed, the cover is pulled back (as shown in step 4), and there is no brake cable in the way, it will give you room to remove the front wheel now.

So the next step would be to loosen and remove the 2 screws that hold the front wheel to the front fork. You will want to do this on both sides.

So now that the front wheel assembly is removed from the bike frame, you can now remove the tire to change the tube or tire as necessary.
